Please note - specifications subject to change without prior notice.
| FRAME | All New Series 4 Alloy Frame, 140mm MultiTrac Suspension, Integrated Battery/Charging Port, 148mm Rear Thru-Axle, Built-in Rear Speed Sensor |
| FORK | RockShock Pike Base 29", Motion Control Damper, 140mm Travel, Maxle Stealth Axle, 42mm Offset |
| SHOCK | RockShox Deluxe Select , Compression and Rebound Adjustment, 210x55, 25xM8 Lower and Upper Mount |
| RIMS | Marin Aluminum Double Wall, 29" Diameter, 29mm Inner Rim Width, Pinned Joint, Disc Specific, Tubeless Compatible |
| HUBS REAR | Shimano HB-TC500, 148x12mm, Centerlock, Standard Freehub Body |
| HUBS FRONT | Shimano FH-TC500, 110x15mm, Centerlock, 32H |
| SPOKES | 14g Black Stainless Steel |
| TIRES | Vee Tire Co Attack HPL, 29x2.5", Top 40 Tubeless Compatible, Override E-Specific Casing |
| DERAILLEUR REAR | Shimano Deore, Direct Attachment, 11-Speed, SGS |
| SHIFT LEVER | Shimano Deore, 11-Speed, I-Spec EV |
| CRANKSET | Shimano EM600, 160mm Length, 38t Chainring |
| MOTOR | Shimano Steps EP6 Drive Unit, 250W, 85Nm, 20MPH Top Assisted Speed |
| CHAIN | KMC X-10E, Silver |
| CASSETTE | SunRace 11-Speed, 11-51T |
| BRAKE FRONT | Tektro Slate EVO, 4-Piston Hydraulic Disc, Resin Pads, 203mm Rotor |
| BRAKES REAR | Tektro Slate EVO, 4-Piston Hydraulic Disc, Resin Pads, 203mm Rotor, w/ Bolt on Speed Sensor |
| BRAKE LEVERS | Tektro Slate EVO Hydraulic Lever, I-Spec EV Compatible |
| HANDLEBAR | Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm Rise, 5ş Up, 9ş Back |
| STEM | Marin 3D Forged Alloy, 35mm |
| GRIPS | Marin Grizzly Lock On |
| HEADSET | FSA No 57E, Sealed Cartridge Bearings, 1 1/8" x 1 1/2” |
| SEATPOST | TranzX, YSP23JL, 1x Remote, Size S 150mm Travel, Size M and L 170mm Travel, Size XL 200mm Travel, 30.9mm |
| SADDLE | Marin eMTB Saddle |
| PEDALS | Marin MTB Plastic |
| BATTERY | Shimano BT-EN806, Internal 630Wh |
| DISPLAY | Shimano SC-E600 |
| SWITCH | Shimano SW-EN600L Left Hand Switch for Assist Mode Change |
| EXTRAS | Shimano Battery Charger EC-E6002, 2A; Shimano CS-EN800 Chainguide, Cap Cush Core Pro Tire Inserts Marin Tire Sealant 300ml, Squeeze Top with Valve Core Removal Tool |
| RANGE, CHARGING TIME | 19-50 miles (Based on Rider Weight, Terrain, Climate and Level of Assist Used), 11 Hours (estimated, under ideal conditions) |
